Xtreme Power Conversion

Xtreme Power Conversion P90 Series P90L-3000 2500VA/2250W 120V UPS module w/493W 72V Charger 2U

Xtreme Power Conversion P90 Series P90L-3000 2500VA/2250W 120V UPS module w/493W 72V Charger 2U

$ 1,885.00 USD
$ 1,885.00 USD
Sale Sold out
Xtreme P90 Series P90L-3000 2500VA/2250W 120V UPS module w/493W 72V Charger 2U (1-input ) L5-30R + (output) 5-15/20R


Deliver clean, continuous power to IT equipment
during power disturbances

Protect your equipment from blackouts, brownouts, sags, surges, and noise interference with the Xtreme Power P90, a true online UPS that delivers continuous high-quality AC power to servers and network equipment with no break when transferring to battery. Available in both tower and rack-mount form factors, the P90 offers the lowest total cost of ownership by cutting energy costs and lowering heat output.

The features and benefits include:
  • 0.9 output power factor delivers more real wattage to high density loads
  • Small footprint with a slim 2U design
  • ECO mode allows for 98% efficient operation and lower energy consumption
  • Smart LCD display enables the monitoring of UPS vitals
  • Frequency converter allows the P90 to be programmed to convert from 50 to 60Hz or 60Hz to 50Hz
  • Multiple communications capability is available through RS-232, USB and Web/SNMP
  • Hot swappable batteries for easy battery replacement without interruption to the load
  • Maximizes uptime for critical loads and equipment by shedding less critical loads
  • The optional XBDM bypass module enables the P90 to be replaced or serviced without interruption of power to attached loads
  • Scalable up to four battery packs for extended runtimes (P90L models)
  • $50,000 load protection policy protects against the damage of connected equipment
MODEL NUMBER P90L-1500 P90L-2000 P90L-3000 P90Lg-3000
CAPACITY AC output 1250VA (1125W) 1700VA (1530W) 2500VA (2250W) 3000VA (2400W)
DC charging 246W 328W 493W 656W
INPUT Voltage range 50–150VAC* 110–300VAC*
Frequency 50/60Hz auto-sensing
OUTPUT Voltage 120VAC nominal (100/110/115VAC selectable)** 208/220/230/240VAC***
Frequency 50/60Hz ± 0.5Hz
THD (full load) < 2%
Overload capacity 125% 2 min; 150% 10 sec; > 150% 1 sec
Crest factor 5:1
BATTERY CHARGER Charger amps 6A
Nominal/float voltage 36/41VDC 48/55VDC 72/82VDC
PHYSICAL UPS dimensions (W x D x H) 17.2 x 18.9 x 3.5 in 17.2 x 18.9 x 3.5 in 17.2 x 25.8 x 3.5 in
UPS weight 33 lbs 35 lbs 47 lbs
Input connection 6 ft, 5–15P 6 ft, 5–20P 6 ft, L5–30P 8 ft, C19 to L6-20P
Output connection (8) NEMA 5–15R (8) NEMA 5–15/20R (1) NEMA L5–30R + (4) NEMA 5–15/20R (1) IEC C19 + (6) IEC C13
ENVIRONMENT Efficiency Up to 98% ECO mode and 92% online mode (90% online mode for P90Lg-3000)
Operating temperature 32–104°F (0–40°C)
Audible noise < 50dBA
Altitude 11,500 ft above sea level
OPTIONAL BATTERY PACKS Model number P90-BP36 P90-BP48 P90-BP72
BP dimensions (W x D x H) 17.2 x 18.9 x 3.5 in 17.2 x 18.9 x 3.5 in 17.2 x 23.6 x 3.5 in
BP weight 58.1 lbs 74.6 lbs 104.4 lbs
Battery quantity/type (6) 12V9AH/36V (8) 12V9AH/48V (12) 12V9AH/72V
APPROVALS UL, cUL, RoHS CE, RoHS
WARRANTY 3 years electronics, 3 years battery warranty (USA and Canada)
COMMUNICATIONS INTERFACE RS-232, USB, EPO, intelligent slot for optional cards (Web/SNMP, Relay/dry contact, Modbus)
INCLUDED IN BOX Software CD, horizontal brackets, tower pedestals, 16 in battery cable kit
AVAILABLE OPTIONS 5 year extended warranty, bypass distribution (XBDM), power distribution (XPDU), 4-post rail kit, 2-post shelf kit

*Depending on load level; **P90L capacity derates 20% at 100V output voltage; ***P90Lg-3000 capacity derates 20% at 208VAC output voltage
