Xtreme Power Conversion
Xtreme Power Conversion P91 Series P91-1000VA/900W 120V 2U UPS
Xtreme Power Conversion P91 Series P91-1000VA/900W 120V 2U UPS
Regular price
$ 999.99 USD
Regular price
$ 1,000.00 USD
Sale price
$ 999.99 USD
Unit price
/
per
Couldn't load pickup availability
Xtreme P91 Series P91-1000 VA/900W 120V 1A Charger 2U (8) 5-15P Output Rack UPS 90000756
Deliver clean, continuous power to IT equipment
during power disturbances
Protect your equipment from blackouts, brownouts, sags, surges, and noise interference with the Xtreme Power P91, a true online UPS that delivers continuous high-quality AC power to servers and network equipment with no break when transferring to battery. Available in both tower and rack-mount form factors, the P90 offers the lowest total cost of ownership by cutting energy costs and lowering heat output.
The features and benefits include:
- 6 ft, 5–15P In / (8) NEMA 5–15R
- 0.9 output power factor delivers more real wattage to high density loads
- Small footprint with a slim 2U design
- Allows for 98% efficient operation and lower energy consumption
- Smart LCD display enables the monitoring of UPS vitals
- Frequency converter allows the P90 to be programmed to convert from 50 to 60Hz or 60Hz to 50Hz
- Multiple communications capability is available through RS-232, USB and Web/SNMP
- Hot swappable batteries for easy battery replacement without interruption to the load
- Maximizes uptime for critical loads and equipment by shedding less critical loads
- The optional XBDM bypass module enables the P90 to be replaced or serviced without interruption of power to attached loads
- Scalable up to four battery packs for extended runtimes (P90L models)
- $50,000 load protection policy protects against the damage of connected equipment
| MODEL NUMBER | P91-1000 | P91-1500 | P91-2000 | P91-3000 | P91g-3000 | |
|---|---|---|---|---|---|---|
| INPUT | Capacity | 1000VA (900W) | 1500VA (1350W) | 2000VA (1800W) | 3000VA (2700W) | 3000VA (2700W) |
| Voltage range | 50–150VAC* | 110–300VAC* | ||||
| Frequency | 50/60Hz auto sensing | |||||
| Surge protection | > 800 J | |||||
| OUTPUT | Voltage | 120VAC nominal (100/110/115 selectable)** | 208/220/230/240VAC*** | |||
| Waveform | Pure sine wave, zero transfer time | |||||
| Frequency | 50/60Hz ± 0.5Hz | |||||
| THD (full load) | < 2% | |||||
| Efficiency | 98% ECO mode, 90% online mode | |||||
| Crest factor | 5:1 | |||||
| Overload capacity | ≤ 130% for 2 min; ≤ 200% for 10 sec; >200% for 1 sec | |||||
| BATTERY | Battery type | Sealed, maintenance-free lead acid | ||||
| Battery quantity and size | (2) 12V 9AH | (3) 12V 9AH | (4) 12V 9AH | (6) 12V 9AH | ||
| Typical recharge | < 4 hours to 90% with 1A charger current | |||||
| PHYSICAL | Dimensions (W x D x H) | 17.2 x 14.9 x 3.5 in | 17.2 x 18.9 x 3.5 in | 17.2 x 25.8 x 3.5 in | ||
| Weight | 29.1 lbs | 41.7 lbs | 47.4 lbs | 65.7 lbs | ||
| Line cord | 6 ft, 5–15P | 6 ft, 5–15P | 6 ft, 5–20P | 6 ft, L5–30P | 8 ft, C19 to L6-20P | |
| Receptacles | (8) NEMA 5–15R | (8) NEMA 5–15/20R | (1) NEMA L5–30R + (4) NEMA 5–15/20R | (1) IEC C19 + (6) IEC C13 | ||
| OPTIONAL BATTERY PACKS | Model number | N/A | P90-BP48 | P90-BP72 | ||
| Dimensions (W x D x H) | N/A | 17.2 x 18.9 x 3.5 in | 17.2 x 23.6 x 3.5 in | |||
| Weight | N/A | 74.6 lbs | 104.4 lbs | |||
| Battery quantity and size | N/A | (8) 12V 9AH / 48V | (12) 12V 9AH / 72V | |||
| ENVIRONMENT | Operating temperature | 32–104°F (0–40°C) | ||||
| Audible noise | < 45dBA | |||||
| Altitude | 11,500 ft above sea level | |||||
| APPROVALS | UL, cUL, RoHS | CE, RoHS | ||||
| WARRANTY | 3 years electronics, 3 years battery warranty (USA and Canada) | |||||
| COMMUNICATIONS INTERFACE | RS-232, USB, EPO, intelligent slot for optional cards (Web/SNMP, Relay/dry contact, Modbus) | |||||
| INCLUDED IN BOX | Software CD, horizontal brackets, tower pedestals, user manual | |||||
| AVAILABLE OPTIONS | 5 year extended warranty, bypass distribution (XBDM), power distribution (XPDU), 4-post rail kit, 2-post shelf kit, wall mount bracket | |||||
