Eaton
Eaton 9PX 9PX1500RTN 1500VA/1350W 120V 2U Rack/Tower UPS w/Network Card
Eaton 9PX 9PX1500RTN 1500VA/1350W 120V 2U Rack/Tower UPS w/Network Card
Regular price
$ 2,999.99 USD
Regular price
$ 3,362.00 USD
Sale price
$ 2,999.99 USD
Unit price
per
Couldn't load pickup availability
Eaton 9PX 9PX1500RTN 1500VA/1350W 120V 2U Rack/Tower UPS w/Network Card
5-15P In / (8) 5-15R Out
Reliable. Versatile. Powerful. Efficient. With double-conversion topology for constant power conditioning and up to 93 percent efficiency, the Eaton 9PX 700-3000 VA models support your overall goal of business continuity. It’s built for scalable deployment, features a graphical LCD for local status updates and integrates with virtualized environments.
| General | |
| Topology | Double-conversion online |
| Configuration | Rack/Tower |
| Color | Black and silver |
| Rating (VA/Watts) | 1500/1350 |
| Diagnostics | Full system self test at power up and ABM test every 30 days |
| UPS Bypass | EHBPL1500R-PDU1U optional |
| Dimensions (H x W x D, inches) | 3.4 (2U) x 17.3 x 17.7 |
| Dimensions (H x W x D, mm) | 86.5 x 440 x 450 |
| Weight (kg) | 19.3 |
| Weight (lbs) | 42.5 |
| Warranty | 2 years |
| Rail Kit Included | 4-post rail kit and tower pedestals included |
| Remote Emergency Power off (REPO) | ROO/RPO: Rear deck emergency stop connectors (for remote on/off and power off) |
| Contents (Ships with the following items) |
9PX1500RTN 1500 VA UPS Network-MS Web/SNMP card 4-post rail kit Safety manual User manual Tower pedestals RS-232 serial cable USB cable Intelligent Power Software Suite CD |
| Efficiency | 90.0% with resistive load |
| Electrical Input | |
| Connection |
(1) NEMA 5-15P
|
| Input Cord | 8 feet |
| Input Voltage Range | Full load: 100-144V, <30% load: 60-144V |
| Nominal Voltage | 120V default (100/110/120/125V) |
| Frequency | 50/60 Hz |
| Frequency Range | 60 Hz: 50–70 Hz, 50 Hz: 40–60 Hz |
| Input Power Factor | >.99 |
| Input Current Distortion | <5% |
| Electrical Output | |
| Nominal Voltage | 120V default (100/110/120/125V) |
| Output voltage regulation | ±1% steady-state |
| Voltage THD | <3% for linear loads |
| Output Receptacles |
(8) NEMA 5-15R
|
| Transfer Time | 0 ms |
| Communications | |
| User Interface | Graphical display. UPS status in a single view. |
| LEDs | 4 status-indicating LEDs |
| Communication Ports | RS-232 (RJ45) ports; USB port as standard (HID). 6-foot RS-232 and USB cables included |
| Communications Card Slots | Network Card-MS included |
| Power Management Software | Eaton Intelligent Power Manager |
| Environmental & Standards | |
| RoHS Compliance | Yes |
| Surge Protection | IEEE ANSI C62.41 Cat B2 |
| Heat Dissipation (BTU) | Online: 512 Battery: 897 (BTU/hr; battery full charged, resistive load) |
| Audible Noise | ≤40 dB at 1 meter |
| Operating Temperature | 0 to 40°C (32°F to 104°F) |
| Safety markings | 0 to 40°C (32°F to 104°F) |
| EMC Markings | IEC 62040-2 Cat C1 / CISPR22 / FCC part 15 Class B / VCCI Class B |
| Storage Temperature | 0 to 35°C (32°F to 95°F); without batteries: -15 to 55°C (5°F to 131°F) |
| Relative Humidity | 0 to 96% non-condensing |
| Altitude | 0-1500m @ 0°C - 40 °C; 1500m-3000m @ 0°C - 35 °C |
